MSZ - 0745
Compact telecentric lenses with 65mm working distances for φ17 camera mount.
More information available upon request
MSZ - 0745
MSZ - 0745
High resolution telecentric bonder lens, with low distortion that is suitable for image processing systems.
The lens use a new C - Mount adapter has a variety of illumination port styles and magnifications.
| Model | Magnification | Working Distance | N.A. | Eff. F-Number | RP (μm) | Max. FOV (mm) | ||
|---|---|---|---|---|---|---|---|---|
|
|
4.16x - 50x
|
14
|
0.1 - 0.45
|
20.8 - 55.6
|
3.4 - 0.75
|
1.5 x 1.2 - 0.1 x 0.1
|
|
|
|
|
2.5x - 30x
|
35.3
|
0.06 - 0.36
|
20.8 - 41.7
|
5.59 - 0.93
|
2.6 x 1.9 - 0.2 x 0.2
|
|
|
|
|
1.25x - 15x
|
46.2
|
0.03 - 0.2
|
20.8 - 37.5
|
11.2 - 1.7
|
5.1 x 3.8 - 0.4 x 0.3
|
|
| Model | Type | Magnification | Working Distance | N.A. | Eff. F-Number | RP (μm) | Max. FOV (mm) | ||
|---|---|---|---|---|---|---|---|---|---|
|
|
Standard Zoom
|
0.55x - 3.6x
|
263.5
|
0.012 - 0.034
|
22.4 - 53.3
|
27.3 - 9.9
|
16 x 12 - 2.4 x 1.8
|
|
|
|
|
Standard Zoom
|
0.37x - 2.23x
|
195
|
0.012 - 0.034
|
4.6 - 25.9
|
23 - 9.3
|
17.2 x 13.0 - 2.9 x 2.2
|
|
|
|
|
Standard Zoom
|
0.7x - 4.5x
|
92.3
|
0.029 - 0.069
|
12.8 - 32
|
11.6 - 4.9
|
9.1 x 6.9 - 1.4 x 1.1
|
|
|
|
|
Internal Focus
|
0.7x - 4.5x
|
92.3
|
0.029 - 0.069
|
12.8 - 32
|
11.6 - 4.9
|
9.1 x 6.9 - 1.4 x 1.1
|
|
